MORI SEIKI NT4200/1000S DCG
Type:
LATHES, COMBINATION, N/C & CNC, (3-axis Or More)
Manufacturer:
MORI SEIKI
Model:
NT4200/1000S DCG
Condition:
Not Specified
Year:
2007
Stock #:
34535
Status:
Sold
Description:
FANUC MSX-711T3 CONTROL WITH MAPPS 3, 8" CHUCKS, 3.6"BORE,
Location:
California, United States
Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.
(1) USED MORI SEIKI NT4200/1000S DCG CNC Multi AXIS TURNING CENTER with LNS Servo Bar Feed Mfg Date 2006
SPECIFICATIONS:
SWING OVER CROSS SLIDE:..............28.7"
DISTANCE BETWEEN CENTERS:............73.3"
MAX TURNING DIA:.....................25.9"
MAX TURNING LENGTH:..................42"
BAR CAPACITY:........................2.5"
X AXIS TRAVEL TOOL SPINDLE:..........29.5
Y AXIS TRAVEL TOOL SPINDLE:..........+/- 8.3"
Z AXIS TRAVEL TOOL SPINDLE:..........44"
B AXIS ROTATION TOOL SPINDLE:.......+/- 120 DEGREES
SPINDLES 1& 2 DRIVE MOTORS:.........34.7 HP
SPINDLES 1 & 2 CHUCKS:...............8"
SPINDLE NOSE:........................JIS A2-8
SPINDLE BORE:........................3.6"
TOOL STORAGE CAP.: ..................100 TOOLS
SPINDLE SPEEDS:......................5,000 (MAIN) 5,000 (SUB) RPM
CLAMP TYPE: COUPLING CLAMP
INDEXING RANGE: 1 DE.
DRIVE MECHANISM: SPEED REDUCER & SERVO MOTOR
ROTATION SPEED: ....................40 MIN
TOOL TO TOOL SPEED: ................1.25 SEC.
TAILSTOCK THRUST: ..................2,203 LBF
MAX. ROTARY TOOL SPINDLE SPEED: ....6,000 RPM
TURRET INDEXING TIME (1-STATION):....0.28 SEC.
EQUIPPED WITH:
MSX 711 IT3 CONTROL
AUTOMATION PACKAGE- 030821 ROV1
ROBOT INTERFACE- MORI SEIKI ETHERNET INTERFACE
POWER DOOR SYSTEM- SAAOPNT42001501
LASER SYSTEM OPTION
8" HOLLOW CHUCK UNIT W/HOLLOW CLY. (88208) MAIN
8" HOLLOW CHUCK UNIT W/HOLLOW CLY. (88208) SUB
AIR BLOW SYSTEM TOOL TIP (TOOL.SPINDLE)
AIR BLOW SYSTEM CHUCK (HEADSTOCK 1)
AUTO IN MACHINE TOOL PRESETTER (TOOL SPINDLE)
S-AXIS INDEX 0.0001 DEGREE
BAR FEEDER INTERFACE
CHIP CONVEYOR HINGE W/DRUM FILTER(RIGHT)/1000
CHUCK HIGH/LOW PRESSURE SYSTEM(HEADSTOCK 1)
CHUCK HIGH/LOW PRESSURE SYSTEM(HEADSTOCK 2)
CONVEYOR 1/F & COVER, PUNCHING BOARD (SIDE)
EARTH LEAKAGE BREAKER
HIGH, PRESSURE COOLANT 1/F. (UP TO 7 MPA -1000PSI)
SPINDLE-1 5,000MIN-1 2211 SKW (NT-4200)
SPINDLE-2 5,000MIN-122/15KW (NT-4200)
SYNCHRONIZED TAPPING SPINDLE CENTER
TOOL SPINDLE CAPTO-C6 (ATC 100)
TOOL STORAGE CAPACITY 100-TOOL
AI CONTOUR CONTROL
DYNAMIC DIAMETER/ RADIUS SWITCHING
FAST ETHERNET
INTERRUPTION TYPE CUSTOM MACRO
INVERSE TIME FEED
PROGRAM RESOLUTION C 1110
PROGRAM RESOLUTION X 10
PROGRAM RESTART
PROGRAMS 1000 + MEMORY 1MB (2560M)
TOOL CENTER POINT FUNCTION (TCP)
TOOL OFFSETS H1: 480
ADDITIONAL M-CODE 5 SET
SPECIFICATIONS:
SWING OVER CROSS SLIDE:..............28.7"
DISTANCE BETWEEN CENTERS:............73.3"
MAX TURNING DIA:.....................25.9"
MAX TURNING LENGTH:..................42"
BAR CAPACITY:........................2.5"
X AXIS TRAVEL TOOL SPINDLE:..........29.5
Y AXIS TRAVEL TOOL SPINDLE:..........+/- 8.3"
Z AXIS TRAVEL TOOL SPINDLE:..........44"
B AXIS ROTATION TOOL SPINDLE:.......+/- 120 DEGREES
SPINDLES 1& 2 DRIVE MOTORS:.........34.7 HP
SPINDLES 1 & 2 CHUCKS:...............8"
SPINDLE NOSE:........................JIS A2-8
SPINDLE BORE:........................3.6"
TOOL STORAGE CAP.: ..................100 TOOLS
SPINDLE SPEEDS:......................5,000 (MAIN) 5,000 (SUB) RPM
CLAMP TYPE: COUPLING CLAMP
INDEXING RANGE: 1 DE.
DRIVE MECHANISM: SPEED REDUCER & SERVO MOTOR
ROTATION SPEED: ....................40 MIN
TOOL TO TOOL SPEED: ................1.25 SEC.
TAILSTOCK THRUST: ..................2,203 LBF
MAX. ROTARY TOOL SPINDLE SPEED: ....6,000 RPM
TURRET INDEXING TIME (1-STATION):....0.28 SEC.
EQUIPPED WITH:
MSX 711 IT3 CONTROL
AUTOMATION PACKAGE- 030821 ROV1
ROBOT INTERFACE- MORI SEIKI ETHERNET INTERFACE
POWER DOOR SYSTEM- SAAOPNT42001501
LASER SYSTEM OPTION
8" HOLLOW CHUCK UNIT W/HOLLOW CLY. (88208) MAIN
8" HOLLOW CHUCK UNIT W/HOLLOW CLY. (88208) SUB
AIR BLOW SYSTEM TOOL TIP (TOOL.SPINDLE)
AIR BLOW SYSTEM CHUCK (HEADSTOCK 1)
AUTO IN MACHINE TOOL PRESETTER (TOOL SPINDLE)
S-AXIS INDEX 0.0001 DEGREE
BAR FEEDER INTERFACE
CHIP CONVEYOR HINGE W/DRUM FILTER(RIGHT)/1000
CHUCK HIGH/LOW PRESSURE SYSTEM(HEADSTOCK 1)
CHUCK HIGH/LOW PRESSURE SYSTEM(HEADSTOCK 2)
CONVEYOR 1/F & COVER, PUNCHING BOARD (SIDE)
EARTH LEAKAGE BREAKER
HIGH, PRESSURE COOLANT 1/F. (UP TO 7 MPA -1000PSI)
SPINDLE-1 5,000MIN-1 2211 SKW (NT-4200)
SPINDLE-2 5,000MIN-122/15KW (NT-4200)
SYNCHRONIZED TAPPING SPINDLE CENTER
TOOL SPINDLE CAPTO-C6 (ATC 100)
TOOL STORAGE CAPACITY 100-TOOL
AI CONTOUR CONTROL
DYNAMIC DIAMETER/ RADIUS SWITCHING
FAST ETHERNET
INTERRUPTION TYPE CUSTOM MACRO
INVERSE TIME FEED
PROGRAM RESOLUTION C 1110
PROGRAM RESOLUTION X 10
PROGRAM RESTART
PROGRAMS 1000 + MEMORY 1MB (2560M)
TOOL CENTER POINT FUNCTION (TCP)
TOOL OFFSETS H1: 480
ADDITIONAL M-CODE 5 SET
