MAZAK QUICK TURN 25L
Type:
LATHES, COMBINATION, N/C & CNC
Manufacturer:
MAZAK
Model:
QUICK TURN 25L
Condition:
Not Specified
Year:
1998
Stock #:
30934
Status:
Sold
Description:
Fusion 640, 10" Chuck
Location:
California, United States
Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.
(1) USED MAZAK 25L CNC TURNING CENTER
NEW: 1998
SPEC:
Chuck Size: 10" (3-Jaw)
Max Diameter Bar Capacity: 2.75" Max Swing Over Bed / Carriage: 20.8" / 15.75" Max Turning Diameter: 12.6" Max Machining Length: 48.03" Main Motor: 25/20 HP AC Spindle Speed: 36 - 3600 RPM Tools: 12D / 24P Spindle Bore 3.15" Spindle Nose A2-8 Spindle Torque 319.7 ft. lbs. Rapid Traverse Rates (X/Z) 708 / 787 IPM X-Axis Travel 7.87" Z-Axis Travel 48.43" Turret Index (Single Step / Full) 0.6 / 1.8 Seconds Tailstock Taper MT #4 Machine Dimensions (L x W x H)
142.9" x 72.8" x 71.9" Machine Weight 12,000 lbs.
FEATURES:
MAZATROL 640 Fusion CNC CONTROL Conversational Programming
12" Monochrome CRT Graphic Display
3.5" Floppy Disc Drive 1.5 MB Memory
48" Cutting Length
10" Hydraulic Chuck
Programmable Tool Eye
Programmable Tailstock Body & Quill
Manual Steady Rest
Chip Conveyor
16 Station Turret
NEW: 1998
SPEC:
Chuck Size: 10" (3-Jaw)
Max Diameter Bar Capacity: 2.75" Max Swing Over Bed / Carriage: 20.8" / 15.75" Max Turning Diameter: 12.6" Max Machining Length: 48.03" Main Motor: 25/20 HP AC Spindle Speed: 36 - 3600 RPM Tools: 12D / 24P Spindle Bore 3.15" Spindle Nose A2-8 Spindle Torque 319.7 ft. lbs. Rapid Traverse Rates (X/Z) 708 / 787 IPM X-Axis Travel 7.87" Z-Axis Travel 48.43" Turret Index (Single Step / Full) 0.6 / 1.8 Seconds Tailstock Taper MT #4 Machine Dimensions (L x W x H)
142.9" x 72.8" x 71.9" Machine Weight 12,000 lbs.
FEATURES:
MAZATROL 640 Fusion CNC CONTROL Conversational Programming
12" Monochrome CRT Graphic Display
3.5" Floppy Disc Drive 1.5 MB Memory
48" Cutting Length
10" Hydraulic Chuck
Programmable Tool Eye
Programmable Tailstock Body & Quill
Manual Steady Rest
Chip Conveyor
16 Station Turret
