MAZAK VORTEX 1400
Type:
Vertical Machining Centers
Manufacturer:
MAZAK
Model:
VORTEX 1400
Condition:
Not Specified
Year:
1999
Stock #:
37735
Status:
Sold
Description:
Fanuc 15iMA, 165"x55"x24", 120 Tools ATC, 10k RPM, CT50
Videos:
Location:
California, United States
Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.
(1) USED MAZAK VORTEX 1400 5-AXIS MACHINING CENTER
NEW 1999
*6/7-Axis Ready
SPECIFICATIONS:
TABLE SIZE .........................(2) 55.1" X 165.5"
TABLE TRAVEL
X - AXIS.................................165"
Y - AXIS.................................55.1"
Z - AXIS.................................24"
A - AXIS (SPINDLE BACK AND FORTH)...+, - 30 DEGREES.
B - AXIS (SPINDLE LEFT AND RIGHT) ...+,- 30 DEGREES
TABLE TOP TO SPINDLE NOSE................5.0" - 34.53"
TABLE LOAD CAPACITY......................11,014 LBS.
RAPID TRAVERSE RATES.....................787 X,Z, IPM
1260 Y IPM
SPINDLE NOSE ............................CT50
SPINDLE SPEED............................10000 RPM
SPINDLE HORSEPOWER.......................50 HP
TOOL MAGAZINE............................60 ATC
TOOL DIA.................................4.92"
TOOL LENGTH..............................15.75"
TOOL WEIGHT..............................44 LBS.
TOOL TO TOOL.............................2.4 SEC
CHIP TO CHIP.............................7.5 SEC.
EQUIPPED WITH:
NURBS INTERPOLATION
PROGRAMABLE MIRROR IMAGE
TOOL RETRACT & RECOVER
TOOL OFFSET AMOUNT MEMORY C
TOOL OFFSET PAIRS : 200
SCALING
DATA SERVER
3-DIMENSIONAL COORDINATE SYS.
CONVERSION
MULTI BUFFER 100 BLOCKS
120 TOOL MAGAZINE
FULLY ENCLOSED OVERCOVERS
PREPARATION FOR 6TH & 7TH AXIS
TSUDAKOMA RNCM 501R W/SCALE
6TH AXIS
7TH AXIS
TSUDAKOMA RNCM 501L W/SCALE
NIAGARA COOLANT 100L/26.4
GAL-MIX *
HIGH PRESSURE COOLANT THRU
SPINDLE SYS. * 213 PSI
CONCEPT 2000 CONVEYOR
STANDARD TRAINING CREDIT
BLOCK 18 UNITS
HIGH COLUMN RISER SPINDLE
NOSE HIGHT 14.84"-38.84
10000RPM
CAT 50
50HP SPINDLE W/ RIX ROTARY JOINT
ALL AVAILABLE MANUALS
**ROTARY TABLE WITH TAIL SUPPORT AVAILABLE ($45,000 ADD.)
**From Major Aerospace Facility, where Ball-Bar tests are done every 3 months.
NEW 1999
*6/7-Axis Ready
SPECIFICATIONS:
TABLE SIZE .........................(2) 55.1" X 165.5"
TABLE TRAVEL
X - AXIS.................................165"
Y - AXIS.................................55.1"
Z - AXIS.................................24"
A - AXIS (SPINDLE BACK AND FORTH)...+, - 30 DEGREES.
B - AXIS (SPINDLE LEFT AND RIGHT) ...+,- 30 DEGREES
TABLE TOP TO SPINDLE NOSE................5.0" - 34.53"
TABLE LOAD CAPACITY......................11,014 LBS.
RAPID TRAVERSE RATES.....................787 X,Z, IPM
1260 Y IPM
SPINDLE NOSE ............................CT50
SPINDLE SPEED............................10000 RPM
SPINDLE HORSEPOWER.......................50 HP
TOOL MAGAZINE............................60 ATC
TOOL DIA.................................4.92"
TOOL LENGTH..............................15.75"
TOOL WEIGHT..............................44 LBS.
TOOL TO TOOL.............................2.4 SEC
CHIP TO CHIP.............................7.5 SEC.
EQUIPPED WITH:
NURBS INTERPOLATION
PROGRAMABLE MIRROR IMAGE
TOOL RETRACT & RECOVER
TOOL OFFSET AMOUNT MEMORY C
TOOL OFFSET PAIRS : 200
SCALING
DATA SERVER
3-DIMENSIONAL COORDINATE SYS.
CONVERSION
MULTI BUFFER 100 BLOCKS
120 TOOL MAGAZINE
FULLY ENCLOSED OVERCOVERS
PREPARATION FOR 6TH & 7TH AXIS
TSUDAKOMA RNCM 501R W/SCALE
6TH AXIS
7TH AXIS
TSUDAKOMA RNCM 501L W/SCALE
NIAGARA COOLANT 100L/26.4
GAL-MIX *
HIGH PRESSURE COOLANT THRU
SPINDLE SYS. * 213 PSI
CONCEPT 2000 CONVEYOR
STANDARD TRAINING CREDIT
BLOCK 18 UNITS
HIGH COLUMN RISER SPINDLE
NOSE HIGHT 14.84"-38.84
10000RPM
CAT 50
50HP SPINDLE W/ RIX ROTARY JOINT
ALL AVAILABLE MANUALS
**ROTARY TABLE WITH TAIL SUPPORT AVAILABLE ($45,000 ADD.)
**From Major Aerospace Facility, where Ball-Bar tests are done every 3 months.
