Machinery Network > Used Inventory > TOYODA FA-450

TOYODA FA-450

Type:

MACHINING CENTERS, HORIZONTAL, N/C & CNC (Incl Pallet Changers)

Manufacturer:

TOYODA

Model:

FA-450

Condition:

Not Specified

Year:

1993

Stock #:

34053

Status:

Sold

Description:

Toyoda FA-450 HMC, (2) 17.7" Pallets, 23.6"x23.6"x23.6", Cat 40, 1993

Location:

Texas, United States

Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.

Quote Request Have one for sale?

For more information call +1 (818) 465-6700 or contact us

Spec Sheet:

(1) USED TOYODA FA-450 HMC HORIZONTAL MACHINING CENTER
MFG. 1993

SPECIFICATIONS:
PALLET SIZE................(2) PALLETS-17.7"X17.7"
TRAVELS OF AXIS
X-AXIS.................................23.6"
Y-AXIS.................................23.6"
Z-AXIS.................................23.6"
PALLET INDEXING........................1 DEGREE
SPINDLE SPEED..........................10,000 RPM'S
SPINDLE TAPER......................CAT 40
SPINDLE NOSE TO TABLE CENTER...........4.92"-28.5"
SPINDLE CENTER TO TABLE TOP............2"-25.6"
SPINDLE MOTOR..........................30 HP
AUTO TOOL CHANGER......................40 POSITIONS, (RANDOM)
RAPID TRAVERSE RATER...................1969 IPM
PALLET LOAD CAPACITY...................882 LBS.
MAX. TOOL DIAMETER.....................2.95"
MAX. TOOL LENGTH.......................13.78"
MAX. TOOL WEIGHT.......................17.6 LBS
MACHINE DIMENSIONS.....................103"X231"
APPROXIMATE WEIGHT.....................25,300 LBS.

EQUIPPED WITH:
15M/CRT DISPLAY CONTROL
150 PSI - COOLANT THRU SPINDLE
M&H PROBING UNIT.
BARNES CHIP CONVEYOR.
RIGID TAPPING.
HELICAL INTERPOLATION.
REMOTE MPG (MANUAL PULSE GENERATOR)
