PARPAS BRAVE MODEL 6000

Type:

MACHINING CENTERS, GANTRY TYPE, N/C & CNC

Manufacturer:

PARPAS

Model:

BRAVE MODEL 6000

Condition:

Not Specified

Year:

2007

Stock #:

33645

Status:

Sold

Description:

PARPAS OMV BRAVE MODEL 6000, HEIDENHAIN TCN i 530 CTRL, 240"X84"X48", HSK 100 TAPER

Location:

Michigan, United States

Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.

Quote Request Have one for sale?

For more information call +1 (818) 465-6700 or contact us

Spec Sheet:

1) USED PARPAS OMV BRAVE MODEL 6000 NEW 2007
SPECIFICATIONS: TABLE DIMS:...........................247” X 109” X-AXIS................................240” Y-AXIS................................84” Z-AXIS................................48” HEAD INDEXES AT.......................001 DEGREE INCREMENTS SPINDLE TAPER.....................HSK 100 SPINDLE SPEED.........................8000 RPM RAPID TRAVERSE X, Y & Z X-....................................236” IPM (6 METERS) Y-....................................82.67” IPM (2.1 METERS) Z-....................................47.24” IPM (1.2 METERS) MAX. FEED RATES X,Y & Z...............600 IPM SPINDLE DRIVE MOTOR (HP)..............28HP TOOL CHANGER SIZE ATC................#40 TOOLS MAX. LOAD ON TABLE....................44,000LBS MIN. ANGLE INDEX SPINDLE HEAD:..4TH INDEXING/ NON-DYNAMIC .001 DEGREE A & B AXIS:...........................5TH INDEXING/ NON-DYNAMIC .001 DEGREE INSTALLED IN PIT:.....................422” X 156” X 32” DEEP
EQUIPPED WITH: HEIDENHAIN TCN I 530 CONTROL VERY LOW HOURS FLOOD COOLANT AROUND SPINDLE COOLANT FILTER RENISHAW SPINDLE PROBE CHILLED HYDRAULICS CHILLED SPINDLE HAND HELD PULSE GENERATOR STEEL TELESCOPING WAY COVERS HYDRAULIC COUNTERBALANCE
