MORI SEIKI NH-4000
Type:
MACHINING CENTERS, HORIZONTAL, N/C & CNC (Incl Pallet Changers)
Manufacturer:
MORI SEIKI
Model:
NH-4000
Condition:
Not Specified
Year:
2004
Stock #:
24423
Status:
Sold
Description:
AVAILABLE FEB; 2APC; 60 ATC; 1 DEGREE; COOLANT THRU.
Location:
United States
Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.
(1) USED MORI SEIKI NH4000 DGC CNC HORIZONTAL
MACHINING CENTER, NEW 2004
SPECIFICATIONS:
TABLE SIZE: 15.748" X 15.748"
NUMBER OF PALLETS: 2 APC
MAX TABLE WORKLOAD: 800 LBS
TRAVELS -X AXIS: 22.047"
-Y AXIS: 22.047"
-Z AXIS: 24.803"
-B AXIS: 1 DEGREE
RAPID TRAVERSE AND CUTTING FEED:1969 IPM (X;Y;Z)
SPINDLE SPEED: 14000 RPM
SPINDLE TAPER: CAT#40
TOOLS: 60 ATC
MAX TOOL DIAMETER: 5.5"
MAX TOOL WEIGHT: 17.60
EQUIPPED WITH:
MORI SEIKI MSG-501 CNC CONTROL
COOLANT THRU SPINDLE
CHIP CONVEYOR
TOOL LENGTH MANAGEMENT
USER MACRO B
EXTENDED WORK OFFSETS
EXTENDED MACRO
HELICAL
DATA SERVER
AI NANO HIGH SPEED MACHINING
MACHINING CENTER, NEW 2004
SPECIFICATIONS:
TABLE SIZE: 15.748" X 15.748"
NUMBER OF PALLETS: 2 APC
MAX TABLE WORKLOAD: 800 LBS
TRAVELS -X AXIS: 22.047"
-Y AXIS: 22.047"
-Z AXIS: 24.803"
-B AXIS: 1 DEGREE
RAPID TRAVERSE AND CUTTING FEED:1969 IPM (X;Y;Z)
SPINDLE SPEED: 14000 RPM
SPINDLE TAPER: CAT#40
TOOLS: 60 ATC
MAX TOOL DIAMETER: 5.5"
MAX TOOL WEIGHT: 17.60
EQUIPPED WITH:
MORI SEIKI MSG-501 CNC CONTROL
COOLANT THRU SPINDLE
CHIP CONVEYOR
TOOL LENGTH MANAGEMENT
USER MACRO B
EXTENDED WORK OFFSETS
EXTENDED MACRO
HELICAL
DATA SERVER
AI NANO HIGH SPEED MACHINING
