AMADA GEMINI FO3015
Type:
LASERS
Manufacturer:
AMADA
Model:
GEMINI FO3015
Condition:
Not Specified
Year:
2000
Stock #:
31186
Status:
Sold
Description:
4000 WATT, 5' X 10', FANUC 160-L
Location:
New York, United States
Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.
We are pleased to offer the following for your consideration: ONE (1) USED 4000 WATT AMADA GEMINI F0-3015 CNC LASER CUTTER 41,500 TOTAL HOURS - LAST TURBO CHANGE @ 31,147 HOURS MFG:2000 1.1 Motion Package Travel Method: Stationary table, X, Y and Z-axis movement for cutting head Control Method: X, Y and Z simultaneous 3 axis control Drive Motors: Fanuc AC servo motors Maximum Sheet Size: 61" (Y) x 122.8" (X) Maximum Axis Travel: 61" (Y) x 122.8" (X) x 7.87" (Z) Maximum Axis Positioning Speed: 3,150 inches per minute (80m/min) per axis (4,554 inches per minute 45o vector. Maximum Speed Z-Axis: 2,362 inches per minute Positioning Accuracy: 0.0004"/20" Maximum Material Weight: 1,875 lbs. Assist Gas: 4 ports with NC pressure Control Machine Footprint: 385" x 107" Machine Weight: 12 Metric Tons Electrical Requirement: 208V, 3 Phase, 60Hz, 10KVA 1.2 CNC Controller Model: Fanuc 160iL - 32 Bit Display: LCD Color Graphics Display Control Function: X, Y, Z-Axis Simultaneous and Focus Lens B-axis, Adaptive Optic and Laser Power control (CW, Gated Pulse, Pierce Routines etc.). Data Input Method: Manual (MDI), Edit, DNC, or 3 " PC compatible disk. Minimum Command Unit: 0.0001" (X, Y, Z) Minimum Travel Unit: 0.0001" (X, Y, Z) Standard Memory: 512K (1280m) Operating Modes: Automatic, MDI and Manual Display Modes: Program Contents, Position Information, Program Check, Settings, Parameters, Beam Diameter Compensation, Assist Gas Status, Self Diagnostics Interlock Displays: Cooling Water Status, Gas Pressure Status, Vacuum Status, Turbo Blower Malfunction, Shutter Status, Beam Power, Resonator Discharge, Door Open, WACS. Electrical requirements: See Motion Package PRICE: $169,500.00
EX WORKS, FORT WORTH, TEXAS
EX WORKS, FORT WORTH, TEXAS
