PEM PEM 800

1)USED PEM 600 PRECISION ELECTROLYTIC MACHINE NEW:2014
** MACHINE IS IN STORAGE AND HAS LESS THAN 100 HOURS**

REPLACEMENT COST: APPROXIMATELY $800K

PEM 600 SPECIFICATIONS: STRUCTURE Exceptionally rigid natural granite frame on vibration-isolating feet. Stationary machining table with integrated stainless steel T-slots. TABLE DIMENSIONS 17.7” x 17.7” (W x D)450 x 450 mm.Worktable height: 37.2” (945 mm) FOOTPRINT 213.9” x 85.04” (W x D)5432 x 2160 mm, includingPEMAQUA 2,000 L electrolyte preparation VERTICAL FEED Air bearing maintenance-free precision direct drive axis. OSCILLATION RANGE Choose at time of order: 0.4mm or 0.2mm MEASURING SYSTEM High resolution absolute linear digital glass scales FIXTURE CLAMPING 4 T-Slots (M12) in table OPERATION Ambient temperature: 60°F to 95°F (15°C to 35°C). The highest precision reached at a constant temperature of 68°F (20°C). Relative humidity max: 75% at 68°F (20°C) GENERATOR Water-cooled modular generator delivers precision pulse power — monitoring
voltage, current and pulse length in the µ-second range. Choice of 1,200 to 9,600 A output (available in increments of 1200 A) ELECTROLYTE PREPARATION The environmentally-friendly PEMAqua electrolyte conditioning system has a multi-chamber tank with overflow protection. The unit filters, backflushes, cools, heats, and adjusts for optimal conductivity and pH; and then safely stores waste. INSTALLATION No special machine foundation or footing required. WEIGHT 4629 lbs (2100 kg) approx. AXES A- and C-axis optional for added versatility CONTROL Using the PEMControl, operators can monitor and adapt all process steps and application parameters for the PEMMachine, PEMPower, and PEMAqua. Program the machining steps and monitor the process in real-time using freely adjustable tolerance bands. Archive your individual program steps, measured values, and error messages for fast analysis and correction. Export for offline evaluation. Includes HMI PC keyboard and 17” touchscreen. SAFETY Real-time process monitoring and optimization. CE certified.
