CMS 5-AXIS IDROLINE S 2040 CNC WATERJET
Type:
WATERJET
Manufacturer:
CMS TECNOCUT
Model:
IDROLINE S2040 5-AXIS
Condition:
Not Specified
Year:
2019
Stock #:
40699
Status:
For Sale
Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.
THE IDROLINE S 2040 WATERJET
CUTTING SYSTEM CONCEIVED AND MANUFACTURED
AS A MACHINE TOOLS. ESPECIALLY SUITABLE FOR
INTENSIVE USE AND MEDIUM/TIGHT TOLERANCES.
AN OUTSTANDING COMPROMISE OF ACCURACY,
RELIABILITY AND TOP PERFORMANCE, IDROLINE S
IS IDEAL FOR ANY KIND OF FABRICATION PROCESS.
IT ALSO PERFECTLY FITS MACHINE SHOPS, LOOKING
FOR A RELIABLE CUTTING SYSTEM FOR PREMACHINING AND ROUGH CUTS.
AXES MOVEMENT
• X (4250 MM – 167’’ - 13,94’ WITH 1 CUTTING HEAD – 4000 MM – 157’’ – 13’ WITH 2 CUTTING HEADS):
THE CUTTING HEAD CROSS MOTION WORKS WITH TEMPERED GROUND GUIDES W/ RECIRCULATING BALLS, FOUR
CONTACT POINTS, DRIVEN BY A HIGH-PRECISION RACK AND PINION SYSTEM.
• Y (2000 MM – 78’’ – 6,5’): LONGITUDINAL MOTION OF THE BRIDGE MOVES ALONG TEMPERED GROUND
GUIDES WITH RECIRCULATING BALLS AND FOUR CONTACT POINTS. THE MOTION IS DRIVEN BY TWO SYNCHRONIZED
MOTORS AND A HIGH-PRECISION RACK AND PINION SYSTEM.
• Z (350 MM – 13.8’’ 3 AXIS HEAD – 250 MM – 9.5 5 AXIS HEAD): VERTICAL MOTION OF THE CUTTING HEAD BY
MEANS OF A TEMPERED GROUND GUIDE WITH RECIRCULATING BALLS, DRIVEN BY A HIGH-PRECISION RACK AND
PINION SYSTEM.
STANDARD TECHNICAL FEATURES *
MM FT INCH /
NET CUTTING AREA X AXIS
NET CUTTING AREA Y AXIS
4250 (4000)
2000
13’ 94’’ (13’ 12’’)
6’ 6’’
167.3’’ (157.48’’)
78.74’’
TABLE SIZE X AXIS
TABLE SIZE Y AXIS
4650
2050
15’ 25’’
6’ 8’’
183’’
80.7’’
Z AXIS STROKE (3 AXIS HEAD)
Z AXIS STROKE (5 AXIS HEAD)
350
250 /
13.8’’
9,8’’
FOOT PRINT L X D X H MAX 5960 x 3900 x 3900 19’ 55’’X 12’ 9’’X 12’9’’ 235’’ X 154’’ X 154’’
XY AXES MAX FEEDRATE 40000 MM/MIN 131 FT/MIN 1570 IPM
ACCELERATION 2 MT / SEC2 131 FT / SEC2 78’’ / SEC2
POSITIONING ACCURACY +/- 0,038 +/- 0,0015
REPEATIBILITY +/- 0,0254 +/- 0,001
ABSORBED POWER 3 KW
MAX LOADING WEIGHT 2000 KG / 4400 LBS
WEIGHT (TANK EMPTY) 4000 KG / 8800LB
CUTTING SYSTEM CONCEIVED AND MANUFACTURED
AS A MACHINE TOOLS. ESPECIALLY SUITABLE FOR
INTENSIVE USE AND MEDIUM/TIGHT TOLERANCES.
AN OUTSTANDING COMPROMISE OF ACCURACY,
RELIABILITY AND TOP PERFORMANCE, IDROLINE S
IS IDEAL FOR ANY KIND OF FABRICATION PROCESS.
IT ALSO PERFECTLY FITS MACHINE SHOPS, LOOKING
FOR A RELIABLE CUTTING SYSTEM FOR PREMACHINING AND ROUGH CUTS.
AXES MOVEMENT
• X (4250 MM – 167’’ - 13,94’ WITH 1 CUTTING HEAD – 4000 MM – 157’’ – 13’ WITH 2 CUTTING HEADS):
THE CUTTING HEAD CROSS MOTION WORKS WITH TEMPERED GROUND GUIDES W/ RECIRCULATING BALLS, FOUR
CONTACT POINTS, DRIVEN BY A HIGH-PRECISION RACK AND PINION SYSTEM.
• Y (2000 MM – 78’’ – 6,5’): LONGITUDINAL MOTION OF THE BRIDGE MOVES ALONG TEMPERED GROUND
GUIDES WITH RECIRCULATING BALLS AND FOUR CONTACT POINTS. THE MOTION IS DRIVEN BY TWO SYNCHRONIZED
MOTORS AND A HIGH-PRECISION RACK AND PINION SYSTEM.
• Z (350 MM – 13.8’’ 3 AXIS HEAD – 250 MM – 9.5 5 AXIS HEAD): VERTICAL MOTION OF THE CUTTING HEAD BY
MEANS OF A TEMPERED GROUND GUIDE WITH RECIRCULATING BALLS, DRIVEN BY A HIGH-PRECISION RACK AND
PINION SYSTEM.
STANDARD TECHNICAL FEATURES *
MM FT INCH /
NET CUTTING AREA X AXIS
NET CUTTING AREA Y AXIS
4250 (4000)
2000
13’ 94’’ (13’ 12’’)
6’ 6’’
167.3’’ (157.48’’)
78.74’’
TABLE SIZE X AXIS
TABLE SIZE Y AXIS
4650
2050
15’ 25’’
6’ 8’’
183’’
80.7’’
Z AXIS STROKE (3 AXIS HEAD)
Z AXIS STROKE (5 AXIS HEAD)
350
250 /
13.8’’
9,8’’
FOOT PRINT L X D X H MAX 5960 x 3900 x 3900 19’ 55’’X 12’ 9’’X 12’9’’ 235’’ X 154’’ X 154’’
XY AXES MAX FEEDRATE 40000 MM/MIN 131 FT/MIN 1570 IPM
ACCELERATION 2 MT / SEC2 131 FT / SEC2 78’’ / SEC2
POSITIONING ACCURACY +/- 0,038 +/- 0,0015
REPEATIBILITY +/- 0,0254 +/- 0,001
ABSORBED POWER 3 KW
MAX LOADING WEIGHT 2000 KG / 4400 LBS
WEIGHT (TANK EMPTY) 4000 KG / 8800LB
GREENJET 69,000 PSI INTENSIFIER
PC BASED OSAI OPEN-M NUMERICAL CONTROL
ELECTRONICALLY CONTROLLED ABRASIVE HOPPER
SOFTWARE LICENSE CAD/CAM TC2020 + JDE POST PROCESSOR
5-AXIS CUTTING HEAD
ANTI COLLISION SYSTEM W/HEIGHT SENSOR
LASER POINTER W/ROTO-TRANSLATION FUNCTION
PHOTO ELECTRIC BARRIERS
AUTOMATIC EXHAUST ABRASIVE EVACUATION W/STAINLESS STEEL CATCH TANK
AUTOMATIC WATER LEVEL ADJUSTMENT SUBMERGED CUTTING - MANUAL
NEW COST OVER $360,000.00
