HAAS VF-6-50TR
Type:
Vertical Machining Centers
Manufacturer:
HAAS
Model:
VF-6-50TR
Condition:
Not Specified
Year:
2010
Stock #:
34843
Status:
Sold
Description:
HAAS VF-6-50TR, 64"X32"X30", CT50, TR-310 TILTING 2 AXIS TRUNNION ROTARY TABLE
Videos:
Location:
California, United States
Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.
(1) USED HAAS VF-6/50TR 5 AXIS VERTICAL MACHINING CENTER
MFG. 2010
FROM AEROSPACE COMPANY !
SPECIFICATIONS:
TRAVELS
X AXIS...........................................64 "
Y AXIS...........................................32 "
Z AXIS...........................................30 "
A AXIS (TILT)...................................±120 °
B AXIS (ROT).....................................360 °
SPINDLE NOSE TO PLATTER (~ MAX)..................20 "
SPINDLE NOSE TO PLATTER (~ MIN).................-10 "
SPINDLE NOSE TO TABLE (~ MAX)....................35 "
SPINDLE NOSE TO TABLE (~ MIN)....................5 "
SPINDLE
MAX RATING.......................................30 HP
MAX SPEED........................................7,500 RPM
MAX TORQUE.......................................450 FT-LB @ 500 RPM
DRIVE SYSTEM.....................................2-SPEED GEARED HEAD
TAPER.........................................CT 50
FEEDRATE
RAPIDS ON X......................................600 IN/MIN
RAPIDS ON Y......................................600 IN/MIN
RAPIDS ON Z......................................600 IN/MIN
MAX CUTTING......................................500 IN/MIN
AXIS MOTORS
MAX THRUST X.....................................3400 LB
MAX THRUST Y.....................................4100 LB
MAX THRUST Z.....................................5600 LB
TRUNNION
PLATTER DIAMETER.................................12.2 "
MAX WEIGHT ON PLATTER............................500 LB
MAX PART SWING (REDUCED AT TILT ANGLES >.± 90°)..31 "
T-SLOT WIDTH.....................................0.625 "
NUMBER OF STD T-SLOTS............................6
PILOT BORE DIA...................................3.250 (+.0005, -0.0) "
PILOT BORE DEPTH.. THROUGH
RAPIDS ON A......................................3000 °/MIN
RAPIDS ON B......................................3000 °/MIN
MAX CUTTING A....................................2000 °/MIN
MAX CUTTING B....................................2000 °/MIN
TOOL CHANGER
TYPE...........................................SMTC
CAPACITY.........................................30+1
MAX TOOL DIAMETER (ADJACENT EMPTY)...............10 "
MAX TOOL DIAMETER (FULL).........................4 "
MAX TOOL LENGTH (FROM GAGE LINE).................16 "
MAX TOOL WEIGHT..................................30 LB
TOOL-TO-TOOL (AVG)...............................4.2 SEC
CHIP-TO-CHIP (AVG)...............................6.3 SEC
GENERAL
AIR REQUIRED.....................................4 SCFM, 100 PSI
COOLANT CAPACITY.................................95 GAL
EQUIPPED WITH:
HAAS 15" COLOR LCD CNC CONTROL
EXPANDED 250 MB MEMORY
USB PORT
ETHERNET
4TH & 5TH AXIS DRIVES AND WIRING
TR-310 TILTING 2 AXIS TRUNNION ROTARY TABLE
ECS-4 EXTENDED CLEARANCE 8" COLUMN RISER
300 PSI THRU SPINDLE COOLANT
HIGH SPEED MACHINING W/ LOOK AHEAD
COORDINATE ROTATION AND SCALING
RIGID TAPPING
95 GALLON FLOOD COOLANT SYSTEM
MULTI AUGER CHIP CONVEYOR SYSTEM
HIGH INTENSITY LIGHTING
EXTENDED Z-AXIS
CUTTING TIME APPROX: 2960 HOURS
*ALL SPECIFICATIONS ARE GENERAL AND SUBJECT TO VERIFICATION
MFG. 2010
FROM AEROSPACE COMPANY !
SPECIFICATIONS:
TRAVELS
X AXIS...........................................64 "
Y AXIS...........................................32 "
Z AXIS...........................................30 "
A AXIS (TILT)...................................±120 °
B AXIS (ROT).....................................360 °
SPINDLE NOSE TO PLATTER (~ MAX)..................20 "
SPINDLE NOSE TO PLATTER (~ MIN).................-10 "
SPINDLE NOSE TO TABLE (~ MAX)....................35 "
SPINDLE NOSE TO TABLE (~ MIN)....................5 "
SPINDLE
MAX RATING.......................................30 HP
MAX SPEED........................................7,500 RPM
MAX TORQUE.......................................450 FT-LB @ 500 RPM
DRIVE SYSTEM.....................................2-SPEED GEARED HEAD
TAPER.........................................CT 50
FEEDRATE
RAPIDS ON X......................................600 IN/MIN
RAPIDS ON Y......................................600 IN/MIN
RAPIDS ON Z......................................600 IN/MIN
MAX CUTTING......................................500 IN/MIN
AXIS MOTORS
MAX THRUST X.....................................3400 LB
MAX THRUST Y.....................................4100 LB
MAX THRUST Z.....................................5600 LB
TRUNNION
PLATTER DIAMETER.................................12.2 "
MAX WEIGHT ON PLATTER............................500 LB
MAX PART SWING (REDUCED AT TILT ANGLES >.± 90°)..31 "
T-SLOT WIDTH.....................................0.625 "
NUMBER OF STD T-SLOTS............................6
PILOT BORE DIA...................................3.250 (+.0005, -0.0) "
PILOT BORE DEPTH.. THROUGH
RAPIDS ON A......................................3000 °/MIN
RAPIDS ON B......................................3000 °/MIN
MAX CUTTING A....................................2000 °/MIN
MAX CUTTING B....................................2000 °/MIN
TOOL CHANGER
TYPE...........................................SMTC
CAPACITY.........................................30+1
MAX TOOL DIAMETER (ADJACENT EMPTY)...............10 "
MAX TOOL DIAMETER (FULL).........................4 "
MAX TOOL LENGTH (FROM GAGE LINE).................16 "
MAX TOOL WEIGHT..................................30 LB
TOOL-TO-TOOL (AVG)...............................4.2 SEC
CHIP-TO-CHIP (AVG)...............................6.3 SEC
GENERAL
AIR REQUIRED.....................................4 SCFM, 100 PSI
COOLANT CAPACITY.................................95 GAL
EQUIPPED WITH:
HAAS 15" COLOR LCD CNC CONTROL
EXPANDED 250 MB MEMORY
USB PORT
ETHERNET
4TH & 5TH AXIS DRIVES AND WIRING
TR-310 TILTING 2 AXIS TRUNNION ROTARY TABLE
ECS-4 EXTENDED CLEARANCE 8" COLUMN RISER
300 PSI THRU SPINDLE COOLANT
HIGH SPEED MACHINING W/ LOOK AHEAD
COORDINATE ROTATION AND SCALING
RIGID TAPPING
95 GALLON FLOOD COOLANT SYSTEM
MULTI AUGER CHIP CONVEYOR SYSTEM
HIGH INTENSITY LIGHTING
EXTENDED Z-AXIS
CUTTING TIME APPROX: 2960 HOURS
*ALL SPECIFICATIONS ARE GENERAL AND SUBJECT TO VERIFICATION
