HAAS VM2
Type:
Vertical Machining Centers
Manufacturer:
HAAS
Model:
VM2
Condition:
Not Specified
Year:
2011
Stock #:
31776
Status:
Sold
Description:
HAAS VM2, 30"x20"x20", 30HP, 12K RPM, NEW 2011
Location:
California, United States
Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.
(1) USED HAAS VM2 CNC VERTICAL MACHINING CENTER (High Accuracy)
NEW 2011 with Transferable One Year Warranty
1600 Cut Hours
SPECIFICATIONS:
TRAVELS:
X-AXIS: ...........................30"
Y-AXIS: ...........................20"
Z-AXIS: ...........................20"
SPINDLE NOSE TO TABLE: ............4"
TABLE: ............................36" X 18"
T-SLOT WIDTH: .....................5/8"
SPINDLE MOTOR: ....................30 HP
MAX. SPEED: .......................12,000 RPM
MAX. TORQUE: ......................75 FT - LB @ 2100 RPM
DRIVE SYSTEM: .....................INLINE DIRECT DRIVE
TAPER: ............................CAT 40
FEEDRATES: RAPIDS ON XYZ: .........710 IPM
TOOL CHANGER CAPACITY: ............24 +1
MAX. TOOL DIAMETER: ...............5"
MAX. TOOL DIAMETER(FULL): .........3"
MAX. TOOL LENGTH: .................11"
TOOL TO TOOL: .....................2.8 SEC.
CHIP TO CHIP (AVG): ...............3.6" SEC.
APPROX MACHINE WEIGHT: ............7,500 LBS.
EQUIPPED WITH:
CHIP AUGER
REMOTE JOB HANDLE
AUTOMATIC AIR GUN
ETHERNET INTERFACE
MACROS COORDINATE ROTATION & SCALING
CTS
POWER FAILURE DETECTION MODULE
750 MB PROGRAM MEMORY
15" COLOR LCD MONITOR
USP PORT
MEMORY LOCK KEYSWTICH
RIGID TAPPING
55 GL. FLOOD COOLANT SYSTEM
NEW 2011 with Transferable One Year Warranty
1600 Cut Hours
SPECIFICATIONS:
TRAVELS:
X-AXIS: ...........................30"
Y-AXIS: ...........................20"
Z-AXIS: ...........................20"
SPINDLE NOSE TO TABLE: ............4"
TABLE: ............................36" X 18"
T-SLOT WIDTH: .....................5/8"
SPINDLE MOTOR: ....................30 HP
MAX. SPEED: .......................12,000 RPM
MAX. TORQUE: ......................75 FT - LB @ 2100 RPM
DRIVE SYSTEM: .....................INLINE DIRECT DRIVE
TAPER: ............................CAT 40
FEEDRATES: RAPIDS ON XYZ: .........710 IPM
TOOL CHANGER CAPACITY: ............24 +1
MAX. TOOL DIAMETER: ...............5"
MAX. TOOL DIAMETER(FULL): .........3"
MAX. TOOL LENGTH: .................11"
TOOL TO TOOL: .....................2.8 SEC.
CHIP TO CHIP (AVG): ...............3.6" SEC.
APPROX MACHINE WEIGHT: ............7,500 LBS.
EQUIPPED WITH:
CHIP AUGER
REMOTE JOB HANDLE
AUTOMATIC AIR GUN
ETHERNET INTERFACE
MACROS COORDINATE ROTATION & SCALING
CTS
POWER FAILURE DETECTION MODULE
750 MB PROGRAM MEMORY
15" COLOR LCD MONITOR
USP PORT
MEMORY LOCK KEYSWTICH
RIGID TAPPING
55 GL. FLOOD COOLANT SYSTEM
