AUTOMA SPEED 1.5D
Type:
BLOW MOLDING MACHINES
Manufacturer:
AUTOMA
Model:
SPEED 1.5D
Condition:
Not Specified
Year:
1986
Stock #:
22176
Status:
Sold
Description:
CONTINUOUS EXTRUSION, SHUTTLE MACHINE, 2 HEADS, 4 BLOW STATIONS, 7 ZONE BC220 TEMP CTRL
Location:
United States
Specifications from OEM brochure and equipped with are described to the best of our knowledge. ALL items should be confirmed by buyer.
AUTOMA MODEL SPEED 1.5D BLOW MOLDER
CONTINUOUS EXTRUSION BLOWMOLDER NEW 1986
STATIONS - DUAL HEAD 4 BLOW STATIONS
EXTRUDER TYPE E 62
SCREW SIZE 60 mm
L/D RATIO 25:1
SCREW SPEED: HDPE RPM 0-88 PVC RPM: 10-50
PLATEN SIZE: 8 1/4"H X 11 1/4" V
DISTANCE BETWEEN CENTERS: 5"
MAXIMUM EXTRUSION HDPE: Kg/Hr 55
PVC: Kg/Hr 60
HEATING ZONES 4
MAX. HEATING POWER 15.3 Kw.
TOTAL MOTOR POWER 18.5 Kw.
MAX. MOLD WEIGHT 100 Kg.
CONTROLS BARBER COLEMAN
MACHINERY NETWORK WILL LOAD THE MACHINE ON A FLATBED TRUCK IN LA MIRADA, CA. 90638.
CONTINUOUS EXTRUSION BLOWMOLDER NEW 1986
STATIONS - DUAL HEAD 4 BLOW STATIONS
EXTRUDER TYPE E 62
SCREW SIZE 60 mm
L/D RATIO 25:1
SCREW SPEED: HDPE RPM 0-88 PVC RPM: 10-50
PLATEN SIZE: 8 1/4"H X 11 1/4" V
DISTANCE BETWEEN CENTERS: 5"
MAXIMUM EXTRUSION HDPE: Kg/Hr 55
PVC: Kg/Hr 60
HEATING ZONES 4
MAX. HEATING POWER 15.3 Kw.
TOTAL MOTOR POWER 18.5 Kw.
MAX. MOLD WEIGHT 100 Kg.
CONTROLS BARBER COLEMAN
MACHINERY NETWORK WILL LOAD THE MACHINE ON A FLATBED TRUCK IN LA MIRADA, CA. 90638.
